SD-BD-04-03/Rev.10/27-02-69

The redundancy module is designed for 24 VDC power systems (20 A). It accepts two 24 VDC input sources (one operating, one standby) and provides a single 24 VDC / 20 A output. Maximum output power: 580 W. DIN rail mounting (TS35/7.5 or TS35/15). Includes LED indicators and a dry contact output for input failure alarm.
