SD-BD-04-03/Rev.09/14-03-68
Switching power supply
ADJUSTABLE DC POWER SUPPLY
DESCRIPTION
The Adjustable DC Power supply adopts high frequency switching power technology. it is controlled by high performance microcomputer. The voltage and current can be adjusted independently. The adjustable power supply widely used in industrial control and electronic products aging and testing. It is suitable for all kinds resistive load, capacitive load, inductive load
FEATURES
- Advance switching mode power supply technology and component, excellent design, small volume, light weight, high efficiency, which ensure the stability and reliability of long-term full-load operation.
- Max Output : 150/300V, 10/20/30A, Max Power : 6000W
- Constant voltage value and constant current value can be continuously adjustable within the range 0 – 100%.
- Digital display output voltage and output current
- Temperature control fan, Over-temperature automatic protection ; Output over – voltage
- Over-current and short-circuit protection ; start up delay soft starting can avoid the over shoot voltage
- when start up.
- Simple operation, convenient use
- Store temperature (-40 ~ 70)°C, working temperature : (-20 ~ 50)°C
- Relative humidity : 90% (40 ±2°C), Atmospheric pressure (70 – 106)kPa
SPECIFICATION
PRODUCT CODING
